RF mini LED Controller--28 keys rgb controller

No.RF-M1 RF-M2 RF-M3 RF-M4 RF-M5

Mini series bluetooth mesh controller is a kind of brand new smart controller. It uses the latest Bluetooth Mesh module and Bluetooth networking technology. Use low power consumption both-way communication Bluetooth mesh chip to make sure controller have longer distance. The latest APP interface design makes the operation of color adjustment, brightness adjustment and saturation adjustment easier, faster and more humanized.The main functions are brightness adjustment, timer, group, scene, call reminder and so on.This controller is with power off memory function, next time to used it, will start with the model it save. Mainly used to control all kinds of constant voltage led products, such as LED source, flexible strip, wall washer, glass curtain wall light and so on.

DIM:

1 Channel

CCT:

2 Channel

RGB:

3 Channel

RGBW:

4 Channel

RGBCW:

5 Channel

Description

Technical Parameters：

- - - - Product name: RF Mini led controller
      - Model No.：RF-M1~M5
      - Working temperature：-20-60℃
      - Input voltage：DC5~24V
      - Connection mode：Common anode
      - controller size：L55.7×W16.6×H10.7mm
      - Net weight：21 keys -30g 28 keys -40g
      - Gross weight：21keys -32g 28 keys -45g
      - Static power consumption：<0.5W
      - Output current：<2A/CH max:6A
      - Output power: Max: 5V:<30W,12V:<72W, 24V:<144W
      - Output control: DIM/CCT/RGB/RGBW/RGBCW LED lamps
      - Certification: CE ROHS

Controller & Remote fuction instruction：

Attention:

Controller’s input voltage is DC5~24V, never connectto others or AC220V, Pls do not overload, the total maxoutput current is 6A;
Before using the infrared remote, the insulating filmshould removed.
Please don’t reverse the power input connection ofboth cathode and anode, please switch on again onlywhen it is in right connection and no short circuit.
Please power off the device if you don’t use it for aquit long time, don’t place in high dust, high temperatureenvironment.

5. Applicable site：TV table, counter, night table, bathroom etc
