Aluminum Shell 360W RGB Amplifier

No.AMF-6

Aluminum Shell 360W RGB Amplifier is suitable for all kinds of constant voltage led RGB controller. it can enlarge the led controller signal through the RGB to receive the PWM(pulse width modulation),and output the signal to the load ,then it can make the same effect with the controller.when add each additional amplifier, can connect and controlled twice more LED lights.theoretically , one controller can connector with thousands of this RGB amplifier, and can make the same effect.

Description

Technical Parameters：

Working temperature：-20-60℃
Input voltage：DC5~24V
Output：3 circuit
Connection mode：Common anode
Product’s size：L85XW62XH20mm
Package size: L88XW66XH22
Net weight：110g
Gross weight：130g
Static power consumption：<1W
Output current：<10A/ch (optional)
Output power：5V:<150W, 12V：<360W；24V：<720W；

Controller Dimention：

External dimension:

Direction for use
Connection description:

Power input interface (port):

Used the plug seat with screw

Load output interface:

Adopt the screw terminal

Connection description：

Connect the input and output wire in sequence according to the specification one the label of the amplifier, make sure that no short circuit phenomenon,then connect the amplifier to the DC5-24V power supply , and used with the led light , the wiring diagram are as follows:

Typical Applications:

Attention:
1. This products Input voltage is DC12V-24V,other input voltage are not allowed.
2. Lead wire should be connected correctly, according to the wire color and the connecting diagram offers.
3. Please do not overload, the total max output current is10A/CH.
4. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector.

Application:
